JVC 4k Monitor

Multi-interface 4K HDR 31.5" studio monitor

DT-U31

The new DT-U Series of 4K displays offers a high-quality solution for 4K monitoring. The DT-U31 31.5" 3840x2160 resolution model features multiple 4K interfaces, supporting 4x 3G-SDI quad link input (both quad and 2SI) and 4K60p HDMI 2.0 input, with built-in 3D LUT auto-calibration. It has a wide colour range and HDR signal support, along with built-in front panel USB colour calibration sensor support, IP remote control, measurement tools and a future SFP slot.

  • TENTATIVE INFORMATION

  • Native Panel resolution 3840 x 2160

  • 31.5-inch UHD 10-bit IPS panel

  • 14 Bit signal processing

  • Wide colour range ITU709 / DCI-P3(99.2%) / BT2020(75.6%)

  • Brightness 300 cd/m²

  • Contrast: 3000:1

  • HLG and PQ-HDR capability

  • 12G-SDI In/Out

  • 4 x 3G-SDI QUAD 4K or HD inputs

  • HDMI 2.0 input

  • SFP future slot

  • Low Latency Mode, for critical audio/video applications

  • Built-in Auto Calibration (only external sensor is needed)

  • Built-in 3D-LUT

  • IP Remote control

  • 16ch audio meters with alert and output selection

  • Waveform monitoring with line selector

  • Vector and histogram tools

  • Signal support up to 4096x2160P 60/50 Hz

  • Flexible gamma selection from 1.0 to 3.0 in 0.1 steps

  • TSL Tally and GPI Tally included on screen marker

  • lost of additional Monitor tools, include Field/Frame selection, Zoom, H/V delay, Focus, RGB Mono, SDI Time code, Safety and screen markers, etc.

  • Comes with a adjustable U-Stand

Connections

Barco Grade 1


Barco's 23” High-Definition reference monitors are an ideal display solution for studio professionals who are performing colour-critical work on a daily basis.

Barco has made use of its long-standing expertise in colour-critical display technology, to offer the market the first true grade-1 LCD display with this level of image quality. As no other professional display solution, Barco's RHDM monitors bring amazing colour accuracy, image stability and motion handling.

The RHDM series bring LCD technology of the highest professional standards, including a true 10-bit, high-speed flat panel, scanning LED backlight technology and embedded calibration and stabilization technology. All these features ensure a colour performance and image quality level that is unseen in broadcast environments. Be it for camera or lighting professionals, editors and post-production staff, anyone who is highly demanding about colors will value Barco's RHDM-2301 or 1701 as an indispensable reference.

Ikegami HEM 2570W Grade 1

The HEM-2570W is the next generation grade 1 monitor with high performance OLED panel. The HEM series incorporate various functions to ensure ideal reference monitoring for a wide range of outside and studio production applications.

Features a 24.5" FHD display at full 1920 x 1080 resolution, 3G-SDI, multi SDI, DVI-D and VBS inputs as standard. Also comes equipped with audio functionality such as speakers and headphone terminal, and USB terminal for image saving, and mouse connection.

Tektronix 5200 Waveform Vector



The WFM5200 Compact Video Waveform Monitor provides an ideal solution for basic video and audio monitoring needs with an integrated high-brightness, low-power consumption LED backlit display. Support for 16 embedded AES/EBU audio, and multiformat support for 3G, HD SDI and SDI.
